    TCP / IP Door Security Access Control Turnstiles RFID Automatic Tripod Turnstile Gate

    Ask Lasest Price
    Brand Name : RONA
    Model Number : RNCF P138
    Certification : CE / ISO9001
    Price : negotiation
    Payment Terms : T/T,
    Supply Ability : 2000 units Per Month
    Delivery Time : 7-15 working days
    • Product Details
    • Company Profile

    TCP / IP Door Security Access Control Turnstiles RFID Automatic Tripod Turnstile Gate

    TCP / IP Door Security Access Control Turnstiles RFID Automatic Tripod Turnstile Gate


    Introduce of tripod turnstile

    RNCF- P138 tripod turnstile is integrated with mechanism, electric and micro-controller and various kinds of identification technologies, compatible with IC,ID, barcode, fingerprint reader and soon to prvoide intelligent control and management to flow control. Durable, anti-rusty. provide orderly passage to people, anti-illegal entry or exit, smooth operation, low noise. arm drops off in condition of emergencies.


    PRODUCT INFORMATION

    (1) Running stable without noise and mechanical impact.
    (2)The passers number can be set by management dept.
    (3) Several working molds optional.
    (4) Bi-direction, or uni-direction. one forbidden, or one direction charged/ one for free pass, and all the working molds set in the main control board.
    (5) Arm's up&down can be remote in long-distance when in fire happened.
    (6) Indicator display guide passer in & out.
    (7) The standard interface compatible with various readers and writer equipments.
    (8) Computer intelligent control turnstiles.
    (9) LED counter display passers total number .Manager can set numbers to 0.
    (10) Card-reading memory cab be set by users.
    (11) Self-check and alarm.

    Parameter of tripod turnstile

    1PowerAC220C±10V,50HZ
    2Operating Temperature-10°C-70°C
    3Relative Humidity≤95%, No Condensation
    4Access Width≤600mm
    5Passing Speed40persons/min(IC Card)
    6Motor0.5NM/24V(Fully Automatic)
    7Input Connection+12V Level Signal or Pulse Wide>100ms DC12V
    8Communication ConnectionRS485 Communication Module Standard.
    9Materialstainless steel 304,thickness is no less than 1.5mm
    10Protection GradeIP54
    11ColourSSB(US32D)- Stainless Steel Brushed / Powder Coating(Optional)
    12Operation PlaceSubway Station, Hoverport,Tourism Sports,Exhibition, Swimming Hall,Residence Area,Enterprise’s Entrance and Exit Attendance,Gateway Guard,Charge Management,Special Access Control

    How does the turnstile work ?

    1. Single/double walkway--controlled in one direction or both
    2. A valid lock action can allow one passage at one time.
    3. Normally open--the machine will unlock when a valid signal is received.
    4. It will lock automatically if passage through turnstile is not completed within pre-set time,the set time can be adjusted via parameter change.
    5. Lightning protection and leakage protection .
    6. Protection functions: anti-pinch, anticollision, antistall, over voltage and over current and powersurge .
    7. Control panel with count and LED digital function
    8. The system is equipped with stepless position device and the operation process is controlled by sensors without mechanical impact .
    9. Digital-controlled (CNC) processing technology, fine surface treatment and corrosion resistance .
    10. Standard external electric interface with photoelectric isolation enchance incorporate all kinds of control equipments thus extremely convenient for system integration .
    11. Remote control and setup .
    12. Extended functions: counting, audible and visual alarm, fire alarm and linkage, Photoelectric Beam Detector
